功率：25W 電壓:單相220V 回轉數: 50/60HZ 1200/1450RPM
軸心:GN斜齒軸 軸心直徑:8mm 起動轉矩:1.3KG/CM
適配減速箱:4GN
齒箱比數扭矩表:
規格:4GN-3-18
| 50HZ 比數 |
3 |
5 |
7.5 |
10 |
12.5 |
15 |
18 |
| 60HZ比數 |
3 |
6 |
9 |
11 |
15 |
18 |
20 |
| 轉 數 |
500 |
300 |
200 |
150 |
120 |
100 |
83 |
| 扭矩25W(4GN) |
4 |
6.7 |
10 |
13 |
16 |
20 |
23 |
| KG/CM |
規格:4GN-20-50
| 50HZ 比數 |
20 |
25 |
30 |
40 |
50 |
| 60HZ比數 |
22 |
30 |
36 |
46 |
60 |
| 轉 數 |
75 |
60 |
50 |
37 |
30 |
| 扭矩15W(4GN) |
26 |
32 |
39 |
52 |
65 |
| KG/CM |
規格:4GN-60-180
| 50HZ 比數 |
60 |
75 |
80 |
90 |
100 |
120 |
150 |
180 |
| 60HZ比數 |
68 |
90 |
95 |
107 |
120 |
172 |
180 |
215 |
| 轉 數 |
25 |
20 |
18 |
16 |
15 |
10 |
10 |
8 |
| 扭矩25W(4GN) |
78 |
80 |
80 |
80 |
80 |
80 |
80 |
80 |
| KG/CM |
25W剎車減速馬達尺寸:
